Case studies
Proof, from point cloud to set-out structure.
Case studies recovered from across the digital thread — more are in production as the project library is rebuilt.
Entertainment & Venues
SSE Arena LED Ribbon Support Package
OD3 Group delivered a new LED ribbon support structure at the SSE Arena Belfast end to end — laser-scanning the exposed-steel bowl, engineering and detailing the steelwork, and setting it out on site so a 5-tonne package fitted first time in a venue that never stopped performing.
Commercial
Applegreen Drive Thru
A multi-level drive-thru structure with external feature steel — hot- and cold-rolled packages coordinated to hold the architectural intent.
Commercial
Applegreen Naas
≈75 tonnes of hot- and cold-rolled steel under a distinctive double-slant roof — full detailing for one of two modern Applegreen buildings by the team.
Industrial & Manufacturing
Blenders Warehouse
≈150 tonnes of warehouse steel — a double-span portal frame with secondary portal, hot- and cold-rolled packages, and a late spiral stair absorbed without delay.
Bluefield · Product Design
Bluefield R500 Houseboat
The R500 houseboat structure — a single welded frame, so a complete home on the water could be craned into place in one lift.
Residential
Church Fields, Block E
A stair core scanned, traced and fitted with architectural balustrades — steel aligned to the concrete as it was actually poured.
Transport Infrastructure
Connolly Station Annex
A multi-storey glazed annex beside Dublin's Connolly Station — ≈46 tonnes of steel detailed around Macalloy bracing, a lift shaft and stair core.
Residential
Florence Road Balconies
Three levels of external balcony steel, detailed and aligned across every floor — delivered direct to the fabricator as one coordinated package.
NHS · Healthcare
Hillingdon Hospital
A design-and-build steel package for the NHS at Hillingdon Hospital — large mid-project changes absorbed without moving the programme.
Residential
Long Mile Road
82 bespoke balconies across four residential blocks — the second large-scale balcony package detailed for the same repeat client.
Civil & Infrastructure
Newcastle 2A Bridge
A new pedestrian bridge detailed from engineering design to fabrication-ready model — every member, parapet and interface coordinated before manufacture.
Culture & Heritage
Shackleton Heritage Gates
New steel gates and grilles for two historic arches — scanned, modelled against the original masonry and detailed to modern standards without touching the old fabric's character.
Culture & Heritage
Shackleton Museum Stair
A curved balustrade for a curved concrete stair — laser-scanned, digitally reconstructed and detailed to ≈7.5 tonnes for the Shackleton Museum.
Terex · Industrial & Manufacturing
Terex Filter Press Enclosure
A filter press enclosure detailed for Terex — open-grid flooring and access stairs, iterated until the stair cleared the tanks below.
Residential
The Willows, Dunshaughlin
Two concrete stair cores laser-scanned and traced to ≈2mm, then detailed with bespoke balustrades — survey, detailing and the engineering calculations in one thread.
Residential
Two Three North Apartments
255 bespoke balconies across four apartment blocks — one of OD3's largest architectural steelwork packages, detailed and delivered through the pandemic.
Underground As-Built Survey
A stone-vaulted underground chamber captured as a colourised point cloud — surveyed in confined conditions and delivered as as-built record drawings.
Commercial
AG Wexford
Reality capture of an existing site for a new-build commercial development — measured ground conditions recorded as the base for design and setting-out.
Civil & Infrastructure
Waste Water Treatment Works
A waste water treatment works captured by 3D laser scanning and modelled to BIM — dense process plant recorded accurately for upgrade and design.
Langford Lodge
An existing building 3D laser-scanned and turned directly into accurate 2D CAD — measured reality captured on site and delivered as scan-to-DWG drawings.
Culture & Heritage
Tertowie House
A characterful existing building captured by 3D laser scanning — recorded accurately as a measured base for refurbishment and design.
Culture & Heritage
Magdalen College, Oxford
Construction visualisation for a project at one of Oxford's historic colleges — the build communicated clearly through a rendered model.
Royal Central School of Speech & Drama
A 4D construction sequence — the build programme visualised against the model, phase by phase, so logistics and timeline can be seen before a component arrives on site.
RCSI Sandyford
A multi-storey building taken through full BIM coordination — every discipline federated into one model and clash-tested in a Navisworks walkthrough before site.
Industrial & Manufacturing
Quarry Scan to BIM
A working quarry and its processing plant captured by 3D laser scanning and rebuilt as an as-built BIM model — measured reality turned into a model you can design against.
Entertainment & Venues
Fr Rocks GAA
A GAA club ground captured by reality capture — the site and its structures recorded accurately as a base for development and design.
Culture & Heritage
Ardboe High Cross
High-resolution 3D laser scanning of a listed 10th-century monument — captured as a colourised point cloud, accurate to ±2mm, for digital archiving and condition record.
